CH40
CH40 is a series of hydraulic powered high-pressure water-blasters from 230 to 1380 Bar and 13 to 74 L/min in flow capacity. The machine are with pneumatic rear wheels with parking brake, castor front wheel. The frames are made up in hot-dip galvanized and powder coated pressed sheet metal parts with all enclosing side frames in stainless steel. It measures 1600 x 1050mm and 1150mm high. One central lifting eye.
Models
Model
Pressure
Flow
CH40-230
230 bar
70 Lpm
CH40-400
400 bar
45 Lpm
CH40-550
550 bar
35 Lpm
CH40-650
650 bar
28 Lpm
CH40-800
800 bar
22 Lpm
CH40-1250
1250 bar
16 Lpm
CH40-1380
1380 bar
13 Lpm
General Specifications
Hydraulic Pressure230 bar
Hydraulic Flow105 Lpm
Engine Power32.8 kW
Dimensions1600mm x 1050mm x 1150 mm (300 kg)
